- FN3280低量程力傳感器中英文產品介紹
- 來源：賽斯維傳感器網 發表于 2014/6/18
Applications: Product Validation Testing, Medical Instruments, Weighing, High Accuracy Measurements, Laboratories and Research
Industries: General Industry
Description: The FN3280 S-beam load cell is designed to measure low loads and comes in standard ranges of 0-0.2 lbf to 0-1 lbf. Integrated mechanical stops protect against accidental overloads up to 100 times F.S. The FN3280 provides a combination of economy and performance; this low cost load cell has an accuracy of 0.1% F.S. With many years of experience as a designer and manufacturer of sensors, Measurement-Specialties often works with customers to design or customize sensors for specific uses and testing environments. To meet your needs we also offer complete turnkey systems. The matched components (sensor, power, amplifier and digital display) are formatted, calibrated and ready for immediate use.
Features:
Full Scale Range from 0-1N to 0-5N [0-0.2lbf to 0-1lbf]
Tension and Compression
Accuracy 0.1% F.S.
Integrated Mechanical Stops
典型應用: 產品驗證測試，醫療設備，稱重，高精度測量，實驗室
行業: 工業控制
產品描述: FN3280是一款專門用來測量低負載的力傳感器，標準量程從0-0.2 lbf 到 0-1 lbf。內置的機械限位使傳感器的過載能力達到滿量程的100倍。FN3280的性價比非常高，精度達到 0.1% F.S.。作為擁有多年經驗的傳感器設計和制造商，MEAS常常與客戶合作，按要求定制適合特殊用途和測試環境的傳感器。同時，我們也根據客戶需要提供成套系統。配套元件（傳感器，電源，放大器和數顯系統）配置統一，經過校正，可供客戶立即使用。
特點:
量程：0-1N 到 0-5N [0-0.2lbf 到 0-1lbf]
拉力和壓力測量
精度：0.1% F.S.
內置的機械限位
FN3280力傳感器更多技術參數及規格書下載請瀏覽：http://plt-connector.com.cn/sensors/578.html
北京賽斯維測控技術有限公司產品咨詢熱線：010-84775646，84775648。
